Tyre Bead Wire
Our tyre bead wire plays a pivotal role in ensuring a safe and seamless driving experience. Crafted from high-quality, high-carbon steel, our tyre bead wire undergoes a rigorous process of drawing and bronze coating to ascertain excellent adhesion with the rubber compounds used in tyre manufacturing.
This enables the wire to securely fasten the tyre onto the rim and withstand the pressure exerted by an inflated tyre, thereby averting potential driving mishaps. Tyre bead wire is crucial for load
transfer, reducing vibrations while driving. Its quality impacts tyre safety, durability and strength. It is an essential part of the automotive industry and ranks third in OEM safety standards.
Product Range
| Diameter | Minimum Breaking Load | |
| Kgf | N | |
| 0.78 mm | 118 | 1156 |
| 0.89 mm | 122 | 1196 |
| 0.96 mm | 132 | 1295 |
| 1.26 mm | 240 | 2352 |
| 1.65 mm | 400 | 3920 |
| 1.83 mm | 484 | 4750 |
| 2.00 mm | 561 | 5500 |
| 2.20 mm | 625 | 6125 |
| 2.40 mm | 750 | 7350 |
| 5.00 mm | 1864 | 18267 |
| Diameter | Minimum Breaking Load | |
| Kgf | N | |
| 0.89 mm | 137 | 1343 |
| 0.96 mm | 158 | 1550 |
| 1.30 mm | 286 | 2803 |
| 1.55 mm | 400 | 4075 |
| 1.60 mm | 426 | 4175 |
We supply any bead wire specification as per customer requirement.
Size - 0.7 to 5 mm
Normal Tin - 1 to 3%
High Tin - 7 to 13%
Packaging
| Item | Option-1 | Option-2 |
| Diameter/Flange | 760 mm | 760 mm |
| Inner Iraverse Width | 305 mm | 350 mm |
| Outer Spool Width | 348 mm | 330 mm |
| Bore/Certer | 33 mm | 33 & 54 mm |
| Drive Pin Slot 1 | 20 mm | 21 mm |
| Drive Pin Slot 2 | 35 mm | 35 mm |
| Winding Capacity | 480+/-20 kgs | 460+/-20 kgs |
| Spool Weight | 73 Kgs | 36 Kgs |
| Item | Option-1 |
| Coil Diameter | 725 mm |
| Care Diameter | 355 mm |
| Net Weight | 460 +/-10 Kgs |
